8.9 LIGHT INPUTS SETTINGS
Work mode can be set as：Feedback input, Control input, Invalid. The control logic is as
following:
System Mode
Light Inputs
Setting
TFT Light
Status
Light Relay
Output Status
Panel Light
Switch
Manuel Mode
Feedback Input
Light Input
Status
Light Input
Status
Valid
Control Input
Light Input
Status
Light Input
Status
Invalid
Invalid
Relay Output
Status
Panel Switch
Valid
Auto Mode
Feedback Input
Light Input
Status
System Control
Invalid
Control Input
Relay Output
Status
System Control
Invalid
Invalid
Relay Output
Status
System Control
Invalid
Stop Mode
Feedback Input
Light Input
Status
Invalid
Invalid
Control Input
Invalid
Invalid
Invalid
Invalid
Invalid
Invalid
Invalid
8.10 BATTERY LOW VOLT WORK MODE
This feature is designed to protect the low battery voltage and ensure that the battery has
enough power to start the unit. When the battery voltage has fallen below the set value, the
unit cranks for a while and charge the battery; after running for a while, the unit will stop
automatically. The work mode can be set as Invalid, Auto Mode Active, Manual Mode Active,
Auto And Manual Mode Active.
8.11 TIMER MODE SELECT
Timer start mode can be set as daily, weekly, monthly and custom week. Users can set the
start time, run duration, scheduled start or scheduled not start function. If the run duration is
set as 00:00, then the unit will not be start.
