8.7 OVER CURRENT ACTION
The formula of over current delay value:
T = t / ((IA/IT)-1)
2
T：Overcurrent delay (second)
t：Timing multiplier ratio
IA：Current max. load current（L1/L2/L3）
IT：Overcurrent setting value
Example：
t = 36
IA = 600A
IT =500A
Conclusion: T = 900s(15 minutes)
8.8 CONDITIONS OF CRANK DISCONNECT SELECTION
No.
Contents
0
Gen frequency (It is DC voltage when fitted with DC generator)
1
Speed sensor
2
Speed sensor + Gen frequency
3
Oil pressure
4
Oil pressure + Gen frequency
5
Oil pressure + Speed sensor
6
Oil pressure + Speed sensor + Gen frequency
