APC715 Pump Unit Controller
APC715 Pump Unit Controller ISSUE 2013-08-28 Version 1.0 Page 32 of 62
No.
Items
Parameter
Default
Description
Curve
curve when select resistor curve
type or current curve type.
Flexible Sensor 1~6
1
Flexible
Sensor
Setting
(0-1)
0
0: Disable；1: Enable (can be set as
temperature/oil pressure/liquid lever
sensor)
2
Curve Type
Depends on sensor type.
3
Open Circuit
Action
(0-2)
0
0:Warn; 1:Shutdown; 2:No action
4
High
Shutdown
(0-9000)
100
Shutdown when external sensor
value is higher than this value. The
delay value and “warn enable” can
be set.
5
Low
Shutdown
(0-9000)
10
Shutdown when external sensor
value is lower than this value. The
delay value and “warn enable” can
be set.
6
High Warn
(0-9000)
90
Warn when external sensor value is
higher than this value. The delay
value, “warn enable” and return
value can be set.
7
Low Warn
(0-9000)
20
Warn when external sensor value is
lower than this value. The delay
value, “warn enable” and return
value can be set.
8
Custom
Curve
Users should set the corresponding
curve when select resistor curve
type or current curve type.
Outlet Pressure Sensor
1
Curve Type
(0-15)
2
2
Open Circuit
Action
(0-2)
1
0:Warn; 1:Shutdown; 2:No action
3
High
Shutdown
(0-9000)%
120
Shutdown when external sensor
value is higher than this value. The
delay value and “warn enable” can
be set.
4
Low
Shutdown
(0-9000)%
10
Shutdown when external sensor
value is lower than this value. The
delay value and “warn enable” can
be set.
5
High Warn
(0-9000)%
110
Warn when external sensor value is
higher than this value. The delay
value, “warn enable” and return
