SolaX Power X1 Series User Manual

Qualifed electrician required for the installation.
Warning!
3.6 Terminals of Inverter
3.5 Dimension
482 mm
417 mm
IntroductionIntroduction
20
21
Object
A
B
C
D
E
F
G
H
I
J
K
L
M
DC switch
PV connection port
Battery connection port
Meter/CT Port
CAN is a reserved port
Grid/EPS (Off-grid) Output port
Communications/ LCD is a reserved port
DRM Port (only for Australia)
USB port for upgrading/ External monitoring connection port
Description
Battery communication port
Ground connection port
Waterproof valve
Fans (only for X1-Hybrid-7.5-D and X1-Hybrid-7.5-M )
A
B
C
D
E F G
I
K
J
K
L
H
M
181 mm
On-grid inverter: Any brand on-grid inverter that supports “Response to
an Increase in Frequency”.
On-grid inverter output power ≤ Max hybrid inverter EPS output power
On-grid inverter output power ≤ Max battery charging power
Battery Quantity
On-grid Inverter
power upper limitation
for T-BAT-5.8
On-grid Inverter
power upper limitation
for T-BAT-3.0
1
2
3
4
3.0 kW
3.0 kW
6.0 kW
6.0 kW
7.5 kW
7.5 kW 7.5 kW
Unsupported
Since hybrid inverter is unable to control on-grid inverter,
therefore hybrid inverter can not achieve zero injection when
loads power + battery charging power < on-grid inverter
output power.
Compatibility
Note :

SolaX Power X1 Series Specifications

General

Brand	SolaX Power
Model	X1 Series
Category	Inverter
Language	English
