SolaX Power X1 Series User Manual

InstallationInstallation
Type
Tool equipment
Name
Name
Safety
gloves
Safety
shoes
Individual
Protection
Tool
5.4 Tool preparation
28
29
Type
Machine Installation Tools
Tool equipment
Bit Φ10
Name
Hammer
drill
Socket
wrench set
(Hexagon)
Torque
screwdriver
Name
Utility knife
Diagonal
pliers
Multifunction
terminal
crimping
tool (RJ45)
Multimeter
Marker
Tape
measure
Protective
glasses
Dustproof
Cover
Individual
Protection
Tools
Rubber
hammer
OT
terminals
press clamp
0.5 mm²~6 mm²
European
terminal
crimping
tool
Hexagon
keys
Spirit level
Crimping
Tool
Crosshead M5
DC Voltage
Range ≥1100 V DC
Diagonal
poliers
Type
Equipment
Preparation
Name
Requirement
Cable
Preparation
Breaker
PV end
wire
EPS(Off-grid)
end wire
Grid end
wire
Communi-
cation lines
PE Cable
Battery
Cable
Double Core Cables
Triple Core Cables
Twisted pair with shield
Conventional wire
Conventional wire
Dedicated PV wire, line number
# 4 mm withstand voltage 1000 V,
temperature resistance 105℃ fire
resistance grade VW-1
Grid port and EPS(Off-grid) port wiring
section
