5 Installation
5.2 Packing List
5.1 Check for Transport Damage
Installation
4.5 EPS (Off-grid) Output (apply to version D/M)
Technical Data
25
24
4.6 Generic Data (apply to version D/M)
*The specific gross weight is subject to the actual situation of the whole machine, which may be a little different
due to the influence of the external environment.
Dimensions (W/H/D) [mm]
Dimensions of Packing (W/H/D) [mm]
Net weight [kg]
Gross weight * [kg]
Heat dissipation treatment
Noise emission (typical) [dB]
Storage temperature range [ ]°C
Operating ambient
Humidity [%]
Altitude [m]
Ingress protection
Protective class
Cold standby consumption
Overvoltage category
Pollution degree
Installation mode
Inverter topology
Communication interface
Standard warranty
Model
Natural Cooling
<30
-40 to +65
-35 to +60 (derating at 45)
0% to 100%
<3000
IP65
I
<3W
X1-Hybrid-3.0 X1-Hybrid-3.7 X1-Hybrid-6.0
III(MAINS), II(PV, Battery)
III
Wall mounted
Non-isolated
Meter/ CT, external control RS485, Dongle series (optional), DRM, USB
Standard 10 years
24 24 24
482*417*181
590*530*315
28 28 28
X1-Hybrid-7.5
25
29
Smart Cooling
<45
Ensure that the inverter is in good condition via transportation. If there
is any visible damage such as cracks, please contact the dealer
immediately.
Open the package and check the materials and accessories
according to the following list.
Q
A
B
C
D
E
G
H
M N
I
J
K
O
P
F
L
Rated EPS Apparent Power [VA]
Nominal EPS Voltage [a.c. V]
Frequency [Hz]
Rated EPS Current [a.c. A]
EPS (Off-grid) Peak Power [VA]
Switching time (typical value) [ms]
Total harmonic distortion (THDv)
Model
X1-Hybrid-3.0
3000
13
X1-Hybrid-3.7
3680
16
X1-Hybrid-6.0
6000
26.1
230VAC
50/60
internal switch<10, external switch＜100
<2%
120%rated,1h
X1-Hybrid-7.5
7500
32.6
100%rated
120%rated,1h
120%rated,10min
X1-Hybrid-5.0
5000
21.7
120%rated,1h
X1-Hybrid-5.0
24
28
X1-Hybrid-5.0K-D
X1-Hybrid-5.0K-D
temperature range [ ]°C
