Firmware Upgrading
Electrical Connection
If it is the first time to boot, please follow the prompts to enter the setting interface.
Ø Before operation, check the inverter according to the following steps
Ø Start the inverter
Please read the following precautions before upgrading.
Warning!
Warning!
Caution!
Caution!
Caution!
7 Firmware Upgrading
Ø Upgrade Notices
Ø Upgrade preparation
6.9 Inverter Operation
74
75
a) Check that the inverter is well xed on the wall.
b) Ensure that all ground wires are well tightened.
c) Ensure that all DC and AC circuit breakers are disconnected.
d) Ensure that all ground wires are well tightened.
e) The AC output terminal is correctly connected to the mains.
f) Ensure that all photovoltaic panels and inverter are properly connected.
Unused DC connectors should be blocked with caps.
Steps to start the inverter
- Turn on the AC switch between the inverter and the power grid.
- (Optional) Remove the locking screw from the DC switch.
- Turn on the DC switch between the PV string and the inverter if there is any.
- Turn on the DC switch at the bottom of the inverter .
When the photovoltaic panel generates enough power, the inverter will start
automatically.
Check the status of the LED and LCD screen, the LED is green, and the LCD
screen displays the main interface.
If the LED is not green, please check the following:
-All connections are correct.
-All external disconnect switches are closed.
-The DC switch of the inverter is set to the "ON" position.
The following are 3 different states of inverter operation, which means that
the inverter starts successfully.
Waiting: When the DC output voltage of the photovoltaic panel is higher than 70V
(lowest starting voltage) and lower than 90V (lowest working voltage), the inverter
waits for checking.
Checking: The inverter will automatically detect the DC input. When the DC input
voltage of the photovoltaic panel is higher than 90V and the photovoltaic panel has
enough energy to start the inverter, the inverter will enter the checking state.
Normal: When the inverter is working normally, the green light is always on. At the
same time, the power is fed back to the grid, and the LCD displays the output power.
Warning!
The input terminal of the inverter can be opened only when all the
installation work of the inverter has been completed. All electrical
connections must be performed by professionals in accordance
with local regulations.
Notice!
If it is the first time to operate the inverter, the system will
automatically display setup guide. Please follow the setup guide
to complete the basic inverter settings.
-In order to upgrade the firmware smoothly, if the DSP
and ARM firmware need to be upgraded, please note that
ARM firmware must be upgraded first, then DSP firmware!
-Please make sure that the category format is correct, do
not modify the firmware file name, otherwise, the inverter
may not work!
-For this inverter, ensure that the PV input voltage is
greater than 100 V (upgrade on sunny days). please ensure
that the battery SOC is greater than 20% or the battery
input voltage is greater than 90 V. Otherwise, it may cause
serious failure during the upgrade process!
-If the ARM firmware upgrade fails or stops, please do not
unplug the U disk power off the inverter and restart it.
Then repeat the upgrade steps.
-If the DSP firmware upgrade fails or stops, please check
whether the power is off. If it is normal, plug in the U disk
again and repeat the upgrade.
1) Please check the inverter version and prepare a U disk (USB 2.0/3.0)
and personal computer before upgrading.
-Please make sure that the size of the U disk is smaller
than 32G, and the format is fat16 or fat 32.
