8.2 Menu Structure
Power 0W
Today 0.0KWh
Battery
80%
Normal
Ø Menu interface
8.3 LCD Operation
System ON/OFF
Work Mode
System Status
Menu
＞
Setting
Setting
Notice:" "This part of the content cannot be set by the end user.
Please contact the installer or us if necessary.
ON/OFF
System
System Status
PV1
PV2
Battery
On-grid
EPS
Meter/CT
EPS
Meter/CT-1
Meter/CT-2
On-grid
Error Log
1
Forced charge
Forced discharge
Stop Chrg&Dischrg
Work Mode
Self Use
Backup mode
Feed-in priority
Manual
2
3
History Data
4
About
Inverter
Battery
Internal Code
6
Settings
5
User settings
Advanced settings
80
81
Date&Time
Language
EPSMute
Self Use Mode
Backup mode
Chrg & Dischrg Period
Feed-in Priority
Dry Contact
User Password
Safety Code
Meter/CT Settings
Grid Parameters
Self Test
FVRT Function
GMPPT
Pu Function
Modbus
Export Control
Power Factor
ExternalGen
DRM Function
Reset
Power Limit
Main Breaker Limit
Battery Heating
EPS Setting
Charger
External ATS
Parallel Setting
ShutDown
MicroGrid
PV Connection
AS4777 Setting
HotStandby Setting
The main interface is the default interface, the inverter will
automatically return to this interface when the system started up
successfully or not operated for a period of time.
The information of the interface is as below. “Power” means the
instant output power; “Today” means the power generated within
the day. “Battery” means the left capacity of battery energy.
The menu interface is another interface for users to change settings
or obtain information.
-When the LCD displays the main interface, click "OK" to enter this
interface.
-The user can select up and down the menu, and press the "OK" key
to confirm.
Pgrid Bias
Advance Password
Peak Shaving
Peak Shaving mode
Exten BAT Func
Battery Charge EVC
Work Mode
System Status
History Data
System ON/OFF
Settings
About
Switch
ON OFF
System ON/OFF
Ø System ON/OFF
"ON" indicates that the inverter is in working state, which is generally
the default state.
“OFF" means that the inverter stops running and only the LCD screen is
turned on.
