64 WHITE BALANCE Menu / PICTURE Menu
WHITE BALANCE
Menu
The WHITE BALANCE menu is used to
select the white balance mode.
MODE (white balance mode)
Select the white balance mode from among
the following:
AUTO, INDOOR, OUTDOOR, ONE
PUSH, MANUAL
When you select MANUAL, R.GAIN (red
gain) and B. GAIN (blue gain) appear. You
can select each item in the range from –128
to +127.
When you select the ONE PUSH
mode
Perform the following operation.
1 Zoom in on a white subject in the
center of the screen.
2 Press the HOME button of the
supplied remote commander.
The one-push white balance adjustment
is activated.
When DISPLAY INFO (page 66) is set to
ON on the SYSTEM menu, the result of the
white balance adjustment is displayed on the
monitor.
PICTURE Menu
APERTURE (aperture compensation)
Select the aperture compensation level from
among MIN, 1 to 14 and MAX.

Sony EVI-HD7V Specifications

General

Maximum resolution	1920 x 1080 pixels
Supported video modes	480p, 720p, 1080i, 1080p
Automatic gain control	Yes
Pan range	-100 - 100 °
Pan speed	300 °/sec
White balance	Auto, Indoor, Manual, Outdoor, Push
Tilt angle range	-25 - 25 °
Camera shutter speed	1/60 - 1/10000 s
Minimum illumination	15 lx
Sensor type	CMOS
Optical sensor size	1/3 \
Digital zoom	40 x
Optical zoom	10 x
Focal length range	3.4 - 33.9 mm
Maximum aperture number	2.1
Built-in HDD	No
Type	CCTV security camera
Placement supported	Indoor
Light exposure modes	Aperture priority AE, Auto, Manual
Connectivity technology	Wired
Form factor	-
Mounting type	Desk
Product color	Gray
Signal-to-Noise Ratio (SNR)	50 dB
DC output voltage	12
Power consumption (typical)	26.4 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Interface	RS-232C
Cables included	AC
Number of cameras	1

Weight and Dimensions

Depth	132 mm
Width	250 mm
Height	152 mm
Weight	1500 g
