3-5-4. BIST Check
1. Playback System Check
1) Set the POWER switch to VTR (or PLAYER) position.
2) Connect the adjustment remote commander and set the HOLD
switch to HOLD (SERVICE) position.
3) Playback the BIST check tape. (XH5-6 (NTSC), XH5-6P
(PAL))
IC1701 (D1) Playback System Check
4) Select page: 4, address: 11, and set data: 04, then press the
PAUSE button.
5) Select page: 4, address: 11, and set data: 00, then press the
PAUSE button.
6) Select page: 4, address: 13, and set data: 03, then press the
PAUSE button.
(The data will be automatically return to “00”.)
7) When the IC1701 (D1) → IC1601 (U1) playback system is
normal, following data will be displayed in page: 4, address:
14 and 15.
8) When the IC1701 (D1) → IC3501 (INDI) playback system is
normal, following data will be displayed in page: 4, address:
16 and 17.
9) When the IC1701 (D1) → IC1901 (A1) playback system is
normal, following data will be displayed in page: 4, address:
18 and 19.
IC1901 (A1) Playback System Check
10) Select page: 4, address: 11, and set data: 10, then press the
PAUSE button.
11) Select page: 4, address: 11, and set data: 00, then press the
PAUSE button.
12) Select page: 4, address: 13, and set data: 04, then press the
PAUSE button.
(The data will be automatically return to “00”.)
13) When the IC1901 (A1) playback system is normal, following
data will be displayed in page: 4, address: 14 and 15.
14) Select page: 4, address: 11, and set data: 08, then press the
PAUSE button.
15) Select page: 4, address: 13, and set data: 07, then press the
PAUSE button.
(The data will be automatically return to “00”.)
16) Select page: 4, address: 11, and set data: 00, then press the
PAUSE button.
17) Perform “Recording System Check”.
Page
4
4
Address
15
14
Data
E5 (NTSC), 27 (PAL)
11 (NTSC), CA (PAL)
Page
4
4
Address
17
16
Data
C0 or BA (NTSC), DC (PAL)
6E or 04 (NTSC), 44 (PAL)
Page
4
4
Address
19
18
Data
33 or B2 (NTSC), A2 (PAL)
59 or 19 (NTSC), 03 (PAL)
Page
4
4
Address
15
14
Data
7B (NTSC), CC (PAL)
B5 (NTSC), C0 (PAL)
