5-11
4. Flange Back Adjustment
The inner focus lens flange back adjustment is carried out
automatically. In whichever case, the focus will be deviated during
auto focusing/manual focusing.
4-1. Flange Back Adjustment (1)
Subject Flange back adjustment chart
(2.0 m from the front of the lens)
(Luminance: 230 ± 30 lux)
Measurement Point
Check operation on TV monitor
Measuring Instrument
Adjustment Page F
Adjustment Address 24 to 2B, 36 to 3D
Switch setting:
1) NIGHT SHOT switch ......................................................OFF
Adjusting method:
1) Check that at both the zoom lens TELE end and WIDE end,
the center of the chart for the flange back adjustment and center
of the exposure screen coincide.
2) Select page: 6, address: 00, and set data: 01.
3) Check that the data of page: F, address: 24 to 2B, 36 to 3D is
the initial value (See table below).
4) Select page: 6, address: 02, and check that the data is “00”.
5) Select page: 6, address: 01, set data: 13, and press the PAUSE
button of the adjustment remote commander.
6) Select page: 6, address: 01, set data: 15, and press the PAUSE
button of the adjustment remote commander.
( The adjustment data will be automatically input to page: F,
addresses: 24 to 2B, 36 to 3D.)
7) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments:
1) Turn OFF the main power supply (8.4V).
2) Perform “Flange Adjustment (2)”.
Address
24
25
26
27
28
29
2A
2B
Data
FB
1D
87
2A
79
13
00
00
Address
36
37
38
39
3A
3B
3C
3D
Data
00
00
46
00
19
00
21
02
4-2. Flange Back Adjustment (2)
Perform this adjustment after performing “Flange Back Adjustment
(1)”.
Subject Subject more than 500m away
(Subjects with clear contrast such as
buildings, etc.)
Measurement Point
Check operation on TV monitor
Measuring Instrument
Adjustment Page F
Adjustment Address 24 to 2B, 36 to 3D
Switch setting:
1) NIGHT SHOT switch ......................................................OFF
Adjusting method:
1) Set the zoom lens to the TELE end and expose a subject that is
more than 500m away (subject with clear contrast such as
building, etc.). (Nearby subjects less than 500 m away should
not be in the screen.)
2) Select page: 6, address: 00, and set data: 01.
3) Select page: 6, address: 02, and check that the data is “00”.
4) Select page: 6, address: 01, set data: 13, and press the PAUSE
button of the adjustment remote commander.
5) Place a ND filter on the lens so that the optimum image is
obtain.
6) Select page: 6, address: 01, set data: 29, and press the PAUSE
button of the adjustment remote commander.
(The adjustment data will be automatically input to page: F,
addresses: 24 to 2B, 36 to 3D.)
7) Select page: 6, address: 02, and check that the data is “01”.
Processing after Completing Adjustments:
1) Select page: 6, address: 00, and set data: 00.
2) Turn OFF the main power supply (8.4V).
3) Perform “Flange Back Check”.
To Next Page
