4-3. SERVICE MODE
1. Setting the Test Mode
Page D Address 10
• Before setting the data , select page: 0, address: 01, and set data:
01.
• For page D, the data set is recorded in the non-volatile memory
by pressing the PAUSE button of the adjustment remote
commander. In this case, take note that the test mode will not be
exited even when the main power is turned off (8.4Vdc).
• After completing adjustments/repairs, be sure to return the data
of this address to 00, and press the PAUSE button of the adjustment
remote commander.
Select page: 0, address: 01, and set data: 00.
2. Emergence Memory Address
Page C Address 30 to 3B
When no error occurs in this unit, data “00” is written in the above
addresses (30 to 3B). when first error occurs in the unit, the data
corresponding to the error is written in the first emergency address
(30 to 33). In the same way, when the second error occurs, the data
corresponding to the error is written in the second emergency address
(34 to 37). Finally, when the last error occurs, the data corresponding
to the error is written in the last emergency address (38 to 3B).
Note: After completing adjustments, be sure to initialize the data of
addresses 30 to 3B to “00”.
Initializing method:
1) Select page: 0, address: 01, and set data: 01.
2) Select page: 3, address: 01, set data: FD, and press the PAUSE
button.
3) Select page: 0, address: 01, and set data: 00.
Function
Normal
Forced camera power ON
Forced VTR power ON
Forced camera + VTR power ON
Data
00
01
02
03
Contents
EMG code when first error occurs
Upper: MSW code when shift starts when first
error occurs
Lower: MSW code when first error occurs
Lower: MSW code to be moved when first error
occurs
EMG code when second error occurs
Upper: MSW code when shift starts when second
error occurs
Lower: MSW code when second error occurs
Lower: MSW code to be moved when second error
occurs
EMG code when last error occurs
Upper: MSW code when shift starts when last error
occurs
Lower: MSW code when last error occurs
Lower: MSW code to be moved when last error
occurs
Address
30
32
33
34
36
37
38
3A
3B
2-1. EMG Code (Emergency Code)
Codes corresponding to the errors which occur are written in
addresses 30, 34 and 38. The type of error indicated by the code are
shown in the following table.
Emergency Type
No error
Loading motor emergency during loading
Loading motor emergency during unloading
T reel emergency during normal rotation
S reel emergency during normal rotation
T reel emergency (Short circuit between S reel
terminal and T reel terminal)
FG emergency at the start up of the capstan
FG emergency at the start up of the drum
FG emergency during normal rotation of the drum
Code
00
10
11
22
23
24
30
40
42
