6-2. ELECTRICAL PARTS LIST
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts
specified in the diagrams or the components
used on the set.
• -XX, -X mean standardized parts, so they may
have some difference from the original one.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering these
items.
• CAPACITORS:
uF: µF
• RESISTORS
All resistors are in ohms.
METAL: metal-film resistor
METAL OXIDE: Metal Oxide-film resistor
F: nonflammable
• COILS
uH: µH
• SEMICONDUCTORS
In each case, u: µ, for example:
uA...: µA... , uPA... , µPA... ,
uPB... , µPB... , uPC... , µPC... ,
uPD..., µPD...
When indicating parts by reference number,
please include the board name.
The components identified by mark ! or
dotted line with mark ! are critical for safety.
Replace only with part number specified.
Les composants identifiés par une marque
! sont critiques pour la sécurité.
Ne les remplacer que par une pièce portant
le numéro spécifié.
Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks
A-7073-520-A AU-202 BOARD, COMPLETE
**********************
(TRV9/TRV9E:EXCEPT AEP,UK)
A-7073-599-A AU-202 BOARD, COMPLETE (TRV9E:AEP,UK)
**********************
(Ref.No.: 30,000 Series)
< CAPACITOR >
C7502 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C7503 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C7504 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C7505 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C7506 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C7507 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7508 1-104-913-11 TANTAL. CHIP 10uF 20% 16V
C7509 1-135-149-21 TANTALUM CHIP 2.2uF 20% 10V
C7510 1-107-820-11 CERAMIC CHIP 0.1uF 16V
C7511 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7513 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C7514 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7515 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7516 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C7517 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7518 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7519 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7521 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7522 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7523 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C7524 1-164-878-11 CERAMIC CHIP 150PF 5% 16V
C7525 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7526 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7527 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7528 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C7529 1-164-878-11 CERAMIC CHIP 150PF 5% 16V
C7532 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C7533 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C7536 1-164-933-11 CERAMIC CHIP 220PF 10% 16V
C7540 1-164-933-11 CERAMIC CHIP 220PF 10% 16V
C7542 1-164-878-11 CERAMIC CHIP 150PF 5% 16V
C7543 1-164-878-11 CERAMIC CHIP 150PF 5% 16V
C7544 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7545 1-164-933-11 CERAMIC CHIP 220PF 10% 16V
C7546 1-164-933-11 CERAMIC CHIP 220PF 10% 16V
C7547 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7559 1-113-682-11 TANTAL. CHIP 33uF 20% 10V
C7560 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C7563 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C7564 1-104-852-11 TANTAL. CHIP 22uF 20% 6.3V
C7565 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C7566 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C7567 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C7572 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C7573 1-135-201-11 TANTALUM CHIP 10uF 20% 4V
C7576 1-113-642-11 TANTAL. CHIP 47uF 20% 10V
C7578 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
(TRV9/TRV9E:EXCEPT AEP,UK)
C7802 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C7803 1-115-467-11 CERAMIC CHIP 0.22uF 10% 10V
C7804 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C7805 1-110-569-11 TANTAL. CHIP 47uF 20% 6.3V
C7806 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 16V
C7807 1-164-938-11 CERAMIC CHIP 0.0015uF 10% 16V
C7808 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C7809 1-104-851-11 TANTAL. CHIP 10uF 20% 10V
C7810 1-165-176-11 CERAMIC CHIP 0.047uF 10% 16V
C7811 1-135-259-11 TANTAL. CHIP 10uF 20% 6.3V
C7812 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7813 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
C7814 1-135-181-21 TANTALUM CHIP 4.7uF 20% 6.3V
C7815 1-164-939-11 CERAMIC CHIP 0.0022uF 10% 16V
C7817 1-109-982-11 CERAMIC CHIP 1uF 10% 10V
C7818 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7819 1-107-826-11 CERAMIC CHIP 0.1uF 10% 16V
C7820 1-164-943-11 CERAMIC CHIP 0.01uF 10% 16V
< CONNECTOR >
CN7501 1-784-680-11 CONNECTOR, BOARD TO BOARD 100P
< DIODE >
D7502 8-719-056-23 DIODE MA2S111-(K8).SO
D7503 8-719-017-76 DIODE MA8030-TX
D7504 8-719-056-23 DIODE MA2S111-(K8).SO
D7506 8-719-421-67 DIODE MA132WK-TX
D7507 8-719-056-23 DIODE MA2S111-(K8).SO
D7508 8-719-056-23 DIODE MA2S111-(K8).SO
D7510 8-719-056-23 DIODE MA2S111-(K8).SO
D7511 8-719-056-23 DIODE MA2S111-(K8).SO
D7512 8-719-421-67 DIODE MA132WK-TX
D7513 8-719-421-67 DIODE MA132WK-TX
D7514 8-719-056-23 DIODE MA2S111-(K8).SO
(TRV9/TRV9E:EXCEPT AEP,UK)
D7801 8-719-056-23 DIODE 1SS387-TPL3
AU-202
