118
HCD-FLX5D/FLX7D
SECTION 8
EXPLODED VIEWS
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
• Items marked “*” are not stocked since they
are seldom required for routine service. Some
delay should be anticipated when ordering
these items.
• The mechanical parts with no reference num-
ber in the exploded views are not supplied.
• Accessories and packing materials are given
in the last of the electrical parts list.
NOTE:
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• Color Indication of Appearance Parts
Example:
KNOB, BALANCE (WHITE) . . . (RED)
↑↑
Parts Color Cabinet's Color
Ref. No. Part No. Description Remark
Ref. No. Part No. Description Remark
1 3-363-099-71 SCREW (CASE 3 TP2)
2 4-252-019-01 COVER (TOP)
3 4-252-039-11 CASE
4 3-363-099-11 SCREW (CASE 3 TP2)
5 4-252-020-01 COVER (BACK)
#1 7-685-646-79 SCREW +BVTP 3X8 TYPE2 N-S
2
3
4
5
not supplied
DSP/GC/MC/MB/REGULATOR boards section
mechanical (cassette) deck section
#1
#1
#1
#1
#1
#1
#1
#1
1
not supplied
4
8-1. COVER SECTION
• Abbreviation
AUS: Australian model
E2 : 120V AC area in Emodel
E3 : 240V AC area in Emodel
E15 : 220V-240V AC area in
EA : Saudi Arabia model
KR : Korean model
MY : Malaysia model
PH : Philippines model
SP : Singapore model
TH : Thai model
