19
HCD-FLX5D/FLX7D
3-15. SUB TRANS BOARD
2
three screw
s
(BVTP3
×
8)
1
connector
(CN902)
1
connector
(CN901)
5
SUB TRANS board
4
ground termina
l
3
3-16. BACK PANEL SECTION
2
two screws
(BVTP3
×
8)
1
connector
(CN902)
4
connector
(CN809)
5
back panel section
2
screw (BVTP3
×
8
)
1
connector
(CN901)
3
