132
HCD-FLX5D/FXL7D
SECTION 9
ELECTRICAL PARTS LIST
BLUE LED
CD DOOR CD DOOR SW1
Ref. No. Part No. Description Remark Ref. No. Part No. Description Remark
NOTE:
• Due to standardization, replacements in the
parts list may be different from the parts speci-
fied in the diagrams or the components used
on the set.
• -XX and -X mean standardized parts, so they
may have some difference from the original
one.
• RESISTORS
All resistors are in ohms.
METAL: Metal-film resistor.
METAL OXIDE: Metal oxide-film resistor.
F: nonflammable
• Items marked “*” are not stocked since they
are seldom required for routine service.
Some delay should be anticipated when order-
ing these items.
• SEMICONDUCTORS
In each case, u: µ, for example:
uA. . : µA. . uPA. . : µPA. .
uPB. . : µPB. . uPC. . : µPC. .
uPD. . : µPD. .
• CAPACITORS
uF: µF
• COILS
uH: µH
•Abbreviation
AUS: Australian model
E2 : 120V AC area in Emodel
E3 : 240V AC area in Emodel
E15 : 220V-240V AC area in
EA : Saudi Arabia model
CD DOOR SW2 CD MOTOR
1-861-348-11 BLUE LED BOARD
**************
< CAPACITOR >
C316 1-164-357-11 CERAMIC CHIP 0.001uF 5% 50V
< LED >
D308 6-500-329-01 LED SELU5E23C-PTP15
(MULTI CHANNEL DECODING)
************************************************************
1-861-349-11 CD DOOR BOARD
**************
< CAPACITOR >
C341 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C342 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C343 1-164-156-11 CERAMIC CHIP 0.1uF 25V
< CONNECTOR >
CN317 1-569-906-11 SOCKET, CONNECTOR 11P
< LED >
D341 8-719-071-41 LED SELS5923C-TP15 (DISC 1 INDICATOR)
D342 8-719-071-41 LED SELS5923C-TP15 (DISC 2 INDICATOR)
D343 8-719-071-41 LED SELS5923C-TP15 (DISC 3 INDICATOR)
D344 8-719-071-41 LED SELS5923C-TP15 (DISC 4 INDICATOR)
D345 8-719-071-41 LED SELS5923C-TP15 (DISC 5 INDICATOR)
< RESISTOR >
R341 1-216-797-11 METAL CHIP 10 5% 1/10W
R342 1-216-813-11 METAL CHIP 220 5% 1/10W
R343 1-216-813-11 METAL CHIP 220 5% 1/10W
R344 1-216-813-11 METAL CHIP 220 5% 1/10W
R345 1-216-813-11 METAL CHIP 220 5% 1/10W
R346 1-216-813-11 METAL CHIP 220 5% 1/10W
R381 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R382 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R383 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R384 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R385 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R386 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R387 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
R388 1-216-829-11 METAL CHIP 4.7K 5% 1/10W
< ROTARY ENCODER >
S341 1-478-516-11 ENCODER, ROTARY (VOLUME)
************************************************************
1-861-351-11 CD DOOR SW1 BOARD
******************
< SWITCH >
S331 1-571-300-21 SWITCH, LEVER SLIDE
(CD/DVD DOOR OPEN/CLOSE DETECT)
************************************************************
1-861-352-11 CD DOOR SW2 BOARD
******************
< SWITCH >
S332 1-771-821-11 SWITCH, PUSH (1 KEY)
(CD/DVD DOOR LOCK DETECT)
************************************************************
CD MOTOR BOARD
***************
< CAPACITOR >
C303 1-164-156-11 CERAMIC CHIP 0.1uF 25V
C305 1-126-964-11 ELECT 10uF 20% 50V
< CONNECTOR >
CN309 1-779-554-21 CONNECTOR, FFC (LIF (NON-ZIF)) 17P
CN312 1-569-906-11 SOCKET, CONNECTOR 11P
CN313 1-785-329-11 PIN, CONNECTOR (LIGHT ANGLE) 3P
CN314 1-785-328-11 PIN, CONNECTOR (LIGHT ANGRE) 2P
< IC >
IC302 8-759-598-69 IC BA6956AN
The components identified by
mark 0 or dotted line with mark
0 are critical for safety.
Replace only with part number
specified.
When indicating parts by reference
number, please include the board.
KR : Korean model
MY : Malaysia model
PH : Philippines model
SP : Singapore model
TH : Thai model
