Board
Name
Board PWB (A side) Detail
BB8
3.6 CI Slot – Cannot Play / No picture / No Sound – Checking Point
54
CI Slot (B-board Checking) – Checking Resistor Part Mounting Points [3/3]
Ref. No. Location Ref. No. Location
RB7003 1 RB7012 6
RB7004 2 RB7020 7
RB7005 3
RB7010 4
Remark:
Confirm these 6 resistors part are mount properly or not.
6
5
4
3
2
1
