DESCRIPTION PART NO.
KD-65X725E KD-65X727E
ECU LA8 AR4 CO1
1 AC COVER(PDT 2L) 4-579-996-01 • • • •
2 LABEL, UNDER TERMINAL (CPN) 4-595-715-21 • • • •
3 REAR COVER (2L_HDN) A 4-691-911-31 • • • •
4 BRACKET, UNDER (FRE) 4-595-951-41 • • • •
5 BRACKET, SIDE (CPN 2L) 4-690-834-11 • • • •
5 BRACKET, SIDE (CPN 2L)
4-690-834-01
n/a n/a n/a n/a
6 SP-BOX ASSY, W25(L)-E 1-859-138-11 • • • •
7 SWITCH UNIT (3M-P) 1-474-647-12 • • • •
8 HOLDER SIDE SW (PDT) 4-579-994-01 • • • •
9
SPACER(17)+C
4-587-424-01 • • • •
10 CARD, WIRELESS LAN 1-458-959-12
• • n/a •
10 CARD, WIRELESS LAN 1-458-959-13 n/a n/a •
11 MOUNTED PWB E-T-CON (65) 1-897-153-11 • • • •
12 GL72-STATIC CONVERTER (TV) 1-474-685-11 • • • •
13 SHEET, INSULATION (PDT 2L) 4-580-889-11
•
•
•
•
14 UNIVERSAL SIL-TU SUT-RA243ZP 8-594-302-70 n/a n/a n/a n/a
14 UNIVERSAL SIL-TU SUT-RT243ZP 8-594-308-30 • • • n/a
14 UNIVERSAL SIL-TU SUT-DB251ZP 8-594-325-00 n/a n/a n/a •
15 COMPL_SVC_BB8_MX_PSU A-2183-111-A n/a n/a n/a n/a
15 COMPL_SVC_BB8_CRECU_PSU A-2185-514-A • n/a n/a n/a
15 COMPL_SVC_BB8_SA_PSU A-2183-103-A n/a • n/a n/a
15 COMPL_SVC_BB8_COL_PSU A-2183-105-A n/a n/a n/a
•
15 COMPL_SVC_BB8_AR_PSU A-2188-860-A n/a n/a •
16 SHEET, THERMAL(BM) 4-549-186-02
•
•
•
•
17 LCD PANEL(W65QWSEB) 1-812-345-11 • • • •
STAND
51 STAND (2L HDN) A 4-687-425-22 • • • •
SMART CORE ASSY
71 PANEL, ORNAMENT (FRE) 4-596-101-01
•
•
•
•
72 GUIDE, LIGHT (FRE) 4-596-102-01 • • • •
73 CASE, BOTTOM (FRE) 4-686-123-02
•
•
•
•
74 COVER, TOP (CPN) 4-596-104-02
•
•
•
•
75 HKZ MOUNT A-2179-172-A
•
•
•
•
61
3-1. KD-65X7*E
3-1-1. Disassembly, Exploded View
!
