122
03.10 Model Number Setting
3) Model Name can be set ONLY ONCE. After user input
data , press <Enter>. Pop dialog will appear to inform
user to confirm data. Press → or ← button to select
YES or NO. Select YES if input data is correct. Select
NO if input data is incorrect. Press <Enter> to save
answer.
4) If YES is selected, the input data is saved into EEPROM.
Model Name EDIT is greyed out and the model name
that has been input is displayed. User will not able to
edit anymore.
* The font color of YES is change to black when it is
selected.
To Next Page
