42
3-1. KD-43X7*E
3-1-1. Disassembly, Exploded View
REF. NO. DESCRIPTION PART NO.
KD-43X720E
KD-43X727E
UC2 LA1 CO1
1 LABEL, UNDER TERMINAL (CPN) 4-595-715-31
•
n/a n/a
1 LABEL, UNDER TERMINAL (CPN) 4-595-715-21 n/a • •
2 REAR COVER (SM CPN) A 4-686-662-01
•
•
n/a
2 REAR COVER (SM CPN) A 4-686-662-21 n/a n/a
•
3 LOUDSPEAKER 1-859-227-21
•
•
•
4 BRACKET, SIDE (FRE) 4-690-594-61 • • n/a
4 BRACKET, SIDE (FRE) 4-690-594-51 n/a n/a •
5 BRACKET, UNDER (FRE) 4-595-951-41 n/a • •
5 BRACKET, UNDER (FRE) 4-595-951-51 • n/a n/a
6 SWITCH UNIT (3M-P-B3) 1-474-647-41 • • •
7 CARD, WIRELESS LAN 1-458-959-12 • • •
8 MOUNTED PWB E-T-CON (43) 1-897-133-11
•
•
•
9 SPRO LD1 BOARD KC 43 A-2184-653-B
•
•
•
10 UNIVERSAL SIL-TU SUT-RA243ZP 8-594-302-70 • • n/a
10 UNIVERSAL SIL-TU SUT-DB251ZP 8-594-325-00 n/a n/a
•
11 SHEET, THERMAL(BAF) 4-457-451-11
•
•
•
12 COMPL_SVC_BB8_UC_ADP A-2183-092-A
•
n/a n/a
12 COMPL_SVC_BB8_MX_ADP A-2183-110-A n/a
•
n/a
12 COMPL_SVC_BB8_COL_ADP A-2183-104-A n/a n/a •
13 SHEET, THERMAL(BM) 4-549-186-02
•
•
•
14 P-MOD (YS7S430HNG0101)(SERVICE A-2180-811-A
•
•
•
STAND
51 STAND BASE (SM FRE) A, N 4-595-693-51
•
•
•
SMART CORE ASSY
71 PANEL, ORNAMENT (FRE) 4-596-101-01
•
•
•
72 GUIDE, LIGHT (FRE) 4-596-102-01
•
•
•
73 CASE, BOTTOM (FRE) 4-596-103-02
•
•
•
74 COVER, TOP (CPN) 4-690-016-01 • • •
75 HKZ MOUNT A-2179-172-A
•
•
•
!
