138
5-1.CIRCUIT BOARD LOCATION
SECTION 5
DIAGRAMS
1. 43”
2. 49”
SWITCH
UNIT
UNIVERSAL
SIL-TU
BB8 BOARD
LD1 BOARD
CARD, WIRELESS
LAN
SWITCH
UNIT
UNIVERSAL
SIL-TU
BB8 BOARD
LD1 BOARD
CARD, WIRELESS
LAN
