3-2. KD-55X7*E
3-2-3. Connectors
WILL BE UPDATED SOON
82
81
83
84
REF.
NO.
DESCRIPTION PART NO. REMARKS
KD-55X700E KD-55X705E KD-55X706E KD-55X720E KD-55X725E KD-55X727E
LA1 BR6 LA8 UC2 LA1 ECU LA8 AR4 CO1
81 CONNECTOR ASSY 30P 1-910-806-14
CN5500(BB8)
-
CN6401(G)(1)
• • • • • • • • •
82 FLEXIBLE FLAT CABLE 5P 1-912-082-11
CN9500(BB8)
-WIFI (1) • n/a • • • • • • •
82 FLEXIBLE FLAT CABLE 5P 1-912-079-11
CN9500(BB8)
-
WIFI (1)
n/a • n/a n/a n/a n/a n/a n/a n/a
83 FLEXIBLE FLAT CABLE 51P 1-912-085-11
CN9000(BB8)
-
TCON (1)
• n/a • • • • • • •
83 FLEXIBLE FLAT CABLE 51P 1-912-074-11
CN9500(BB8)
-WIFI (1) n/a • n/a n/a n/a n/a n/a n/a n/a
84 HARNESS ASSY 1-910-806-13
CN9501(BB8)
-
CN203(SM)
-
CN001(HKZ)(1)
•
•
•
•
•
•
•
•
•
