Sony KD-43X720E - Slide Number 48

48
3-1. KD-49X7*E
3-1-1. Disassembly, Exploded View
REF.
NO.
DESCRIPTION PART NO.
KD-49X705E KD-49X720E
KD-49X706E KD-49X727E KD-49X700E KD-49X725E
BR6 UC2 LA1 LA8 CO1 LA1 LA8 ECU AR4
1 LABEL, UNDER TERMINAL (CPN) 4-595-715-31 n/a • n/a n/a n/a • n/a n/a n/a
1 LABEL, UNDER TERMINAL (CPN) 4-595-715-21 • n/a • • • n/a • • •
2 REAR COVER (M CPN) A 4-696-413-01 n/a • • • n/a • n/a n/a n/a
2 REAR COVER (M CPN) A 4-696-413-21 n/a n/a n/a n/a • n/a • • •
2 REAR COVER (M CPN) A A-2186-166-A • n/a n/a n/a n/a n/a n/a n/a n/a
3 LOUDSPEAKER 1-859-227-21 n/a • • • • • • • •
3 LOUD SPEAKER ASSY KC49 INCH A-2189-397-A •
n/a n/a n/a n/a n/a n/a n/a n/a
4 BRACKET, SIDE (FRE) 4-690-594-61 n/a • • • n/a • n/a n/a n/a
4 BRACKET, SIDE (FRE) 4-690-594-51 n/a n/a n/a n/a • n/a • • •
4 BRACKET, SIDE (FRE) A-2186-058-A • n/a n/a n/a n/a n/a n/a n/a n/a
5 BRACKET, UNDER (FRE) 4-595-951-41 n/a n/a • • • n/a • • •
5 BRACKET, UNDER (FRE) 4-595-951-51 n/a • n/a n/a n/a • n/a n/a n/a
5 BRACKET, UNDER (FRE) A A-2186-057-A • n/a n/a n/a n/a n/a n/a n/a n/a
6 SWITCH UNIT (3M-P-B3) 1-474-647-41 n/a • • • • •
• • •
6 SWITCH UNIT (3M-P-B3) KIT A-2186-185-A • n/a n/a n/a n/a n/a n/a n/a n/a
7 CARD, WIRELESS LAN 1-458-959-12 • • • • • • • • •
8 MOUNTED PWB E-T-CON (49) 1-897-134-11
•
•
•
•
•
•
•
•
•
9 SPRO LD1 BOARD KC 49 A-2184-654-B n/a
•
•
•
•
•
•
•
•
9 LD1_2DRV_49C_BR6 MOUNT A-2186-081-A
•
n/a n/a n/a n/a n/a n/a n/a n/a
10 SHEET, THERMAL(BAF) 4-457-451-11
•
•
•
•
•
•
•
•
•
11 UNIVERSAL SIL-TU SUT-RA243ZP 8-594-302-70 n/a
•
•
•
n/a
•
n/a n/a n/a
11 UNIVERSAL SIL-TU SUT-RT243ZP 8-594-308-30
•
n/a n/a n/a n/a n/a
•
•
•
11 UNIVERSAL SIL-TU SUT-DB251ZP 8-594-325-00 n/a n/a n/a n/a
•
n/a n/a n/a n/a
12 COMPL_SVC_BB8_UC_ADP A-2183-092-A n/a
•
n/a n/a n/a
•
n/a n/a n/a
12 COMPL_SVC_BB8_BZ_ADP A-2183-106-A
•
n/a n/a n/a n/a n/a n/a n/a n/a
12 COMPL_SVC_BB8_MX_ADP A-2183-110-A n/a n/a
•
•
n/a n/a n/a n/a n/a
12 COMPL_SVC_BB8_SA_ADP A-2183-102-A n/a n/a n/a n/a n/a n/a
•
n/a n/a
12 COMPL_SVC_BB8_CRECU_ADP A-2185-513-A n/a n/a n/a n/a n/a n/a n/a
•
n/a
12 COMPL_SVC_BB8_COL_ADP A-2183-104-A n/a n/a n/a n/a
•
n/a n/a n/a n/a
12 COMPL_SVC_BB8_AR_ADP A-2188-859-A n/a n/a n/a n/a n/a n/a n/a n/a
•
13 SHEET, THERMAL(BM) 4-549-186-02
•
•
•
•
•
•
•
•
•
14 P-MOD ( YS7S490HNG0101)(SERVICE A-2180-813-A
•
•
n/a
•
n/a
•
n/a n/a n/a
14 P-MOD (YS7S490HNG0101)(SERVICE A-2180-814-A n/a n/a
•
n/a
•
n/a
•
•
•
STAND
51 STAND BASE (M FRE) A, N 4-595-697-51 n/a • n/a • n/a n/a n/a n/a n/a
51 STAND BASE (M FRE) A, N A-2186-168-A • n/a n/a n/a n/a n/a n/a n/a n/a
51 STAND BASE (M FRE) A, N 4-595-697-31 n/a n/a • n/a • • • • •
SMART CORE ASSY
71 PANEL, ORNAMENT (FRE) 4-596-101-01 • • • • • • • • •
72 GUIDE, LIGHT (FRE) 4-596-102-01 • • • • • •
• • •
73 CASE, BOTTOM (FRE) 4-596-103-02
•
•
•
•
•
•
•
•
•
74 COVER, TOP (CPN) 4-690-016-01
•
•
•
•
•
•
•
•
•
75 HKZ MOUNT A-2179-172-A n/a
•
•
•
•
•
•
•
•
75 HKZ BR MOUNT
A-2186-086-A
•
n/a n/a n/a n/a n/a n/a n/a n/a
!
!
