107SR 430, SR 450
12. Special Servicing Tools
New Special Tools
Existing Special Tools
No. Description Part No. Application Rem.
1 Clamping strap 4244 893 2600 Installing the piston 1)
No. Description Part No. Application Rem.
1 Pump 0000 850 1300 Testing engine and carburetor for leaks
2 Sealing plate 0000 855 8106 Sealing the exhaust port
- Hose for leakage test 1110 141 8600 Testing carburetor for leaks
- Nipple 0000 855 9200 Testing carburetor for leaks
3 Locking strip 0000 893 5904 Blocking the crankshaft
4 Screwdriver bit, T 27 x 125 0812 542 2104 Removing and installing spline socket
(IS) screws with electric or pneumatic
screwdrivers; tightening down screws
with torque wrench
1)
5 Threaded bushing 1108 893 4500 Holding engine pan with puller
5910 890 4400
6 Assembly drift 1108 893 4700 Removing and installing piston pin
7 Installing sleeve 1118 893 4602 Protects oil seal at fan side
8 Setting gauge 4118 890 6401 Adjusting air gap between the ignition
module and flywheel
9 Combination wrench 4119 890 3400 Releasing nuts and screws 1)
10 Test flange 5910 850 4200 Leakage Test
11 Ignition system tester, ZAT 4 5910 850 4503 Testing ignition system
12 Ignition system tester, ZAT 3 5910 850 4520 Testing ignition system
13 Torque wrench 5910 890 0302 0.5 to 18 Nm
14 Torque wrench 5910 890 0312 6 to 80 Nm
15 Installing tool 12 5910 890 2212 Installing hookless snap ring in piston
16 Screwdriver 5910 890 2305 Adjusting carburetor
- Setting disk 5910 893 6600 Add-on for screwdriver (adjusting
carburetor)
17 Screwdriver Q-SW 8x200 5910 890 2420 Carburetor nuts 1)
18 Screwdriver bit, T 27 x 200 5910 890 2415 IS-P screws (4 mm) 1)
19 Puller 5910 890 4501 Removing limiter caps
20 Crimping tool 5910 890 8210 Attaching connectors to electrical wires
21 Puller 5910 893 0801 Releasing flywheel 1)
22 Sleeve 5910 893 1706 Sleeve for installing tool 12
23 Socket DIN 3124, 13 mm 5910 893 5608 Removing flywheel nut
