6 SR 430, SR 450
2.4 Tightening Torques
DG and P (Plastoform) screws are used in polymer and light metal components. These screws form a
permanent thread when they are installed for the first time. They can be removed and installed as often as
necessary without impairing the strength of the screwed assembly, providing the specified tightening torque is
observed.
For this reason it is essential to use a torque wrench.
Fastener Thread size For component Torque Remarks
Nm
Screw P 5x18 Shroud/blower housing 4.0 2)
Screw P 4x12 Cover/housing 2.0
Screw P 5x18 Cover/inner handle molding 2.0
Screw P 5x18 Antistatic/blower housing 4.0
Screw P 5x25 Pressure pump/blower housing 3.0
Screw M 5x21 Filter cover/filter housing 4.0
Screw P 5x18 Filter housing/blower housing 4.0
Nut M 5 Filter housing/carburetor/baffle 3.5
Screw P 6x25 Blower housing/bearing plug 6.0
Screw P 5x18 Blower housing, outer/inner 4.0
Screw D 6x32 Blower housing, inner/engine pan 12.0 3)
Screw D 6x32 Blower housing, inner/cylinder 12.0 3)
Nut M 10x1 Blower wheel/crankshaft/nut 30.0
Screw P 5x18 Housing/blower housing 4.0
Screw P 4x19 Handle molding, outer/inner 1.5
Screw P 6x21.5 Handle molding/blower tube 4.0
Screw P 6x25 Lever/inner handle molding 4.0
Screw M 4x9.6 Exhaust pipe/muffler 4.0
Screw M 6x28 Engine pan/cylinder, stage 1 4.0 3), 5)
Screw M 6x28 Engine pan/cylinder, stage 2 12.0 3)
Screw P 5x18 Air guide shroud/blower housing 4.0
Screw P 4x19 Detent spring/inner handle molding 1.5
Screw P 6x25 Backplate/bearing plug 6.0
Screw P 6x25 Backplate/tank housing 6.0
Screw P 6x25 Backplate/bracket 6.0
Screw P 5x14 Back padding/backplate 2.5
Screw M 5x18 Muffler/cylinder, top, gasket 8.0 3)
Screw M 5x18 Muffler/cylinder, bottom 8.0 3)
Screw P 6x21.5 Hose clamp/blowing attachment 1.5
Nut M 8x1 Flywheel/crankshaft 20.0 4)
Screw P 5x18 Strainer/blower housing 3.0
Screw M 5x18 Starter cover/shroud/engine pan 6.0 3)
Screw M 5x18 Starter cover/shroud/cylinder 6.0 3)
Screw P 4x12 Shaft/rotary shutter 2.5
