Sungrow Logger1000 User Manual

5 Mechanical Installation User Manual
20
5.6 Installing Power Box
Mount the power box onto the concrete wall or metal surface according
to onsite conditions.
Secure the power box via the buckles (as shown in the figure below) on the back of
it.
Buckle
Step 1 Install and secure the power box guide rail at the appropriate location.
Step 2 Tilt the power box and hook the buckle into the guide rail. Press down the
power box until it snaps into place with an audible "Click" sound.
1
2
