4 Mechanical Mounting User Manual
30
Forward tilt Backward tilt
Horizontally
Upside down
4.2.4 Installation Clearance Requirements
Reserve enough clearance around the inverter to ensure sufficient space for
heat dissipation. Clearance requirement and multiple installation:
400 mm 400 mm
400 mm
800 mm
For multi-row installation, the distance between two adjacent rows must be at
least 400 mm.
4.3 Installation Tools
Installation tools include but are not limited to the following recommended ones.
If necessary, use other auxiliary tools on site.
General tools (recommended)
Marker
Measuring tape
Utility knife
Multimeter
Measurement range: ≥
1100Vdc
880.0
Wrist strap
Protective gloves
