28
6 Electrical Connection
Once the inverter is firmly attached to the appropriate location, it can be connected
to the PV power system.
Installation shall comply with local regulations and technical rules. Installation shall
comply with the relevant instructions of AS 4777.1. All electrical connection should
follow the National Wiring Rules of Standard AS/NZS 3000.
Improper operation during the wiring process can cause fatal injury to the
operator or unrecoverable damage to the inverter.
Only qualified personnel can perform the wiring work.
Prior to any electrical connection, keep in mind that inverter has dual power
supplies. It is mandatory for technical personnel to wear personal protective
equipment: helmet, footwear and gloves during the electrical work.
6.1 Terminals Description
All electrical terminals and cable openings of the inverter are located at the
connection cabinet as Fig. 6-1.
