Suzuki drz 400E Service Manual

6-30 CHASSIS
REAR WHEEL
Adjust the drive chain slack after installing the rear wheel
axle. (
2-16 and 2-17)
Tighten the rear axle nut to the specified torque.
Rear axle nut:
100 N·m (10.0 kgf-m, 72.5 lb-ft).. for E-03, 28
110 N·m (11.0 kgf-m, 79.5 lb-ft).. for the other countries
NOTE:
After installing the rear axle nut, insert a new cotter pin into
the rear axle. (E-03, 28)
After remounting the rear wheel, pump the brake pedal a few
times to check for proper brake operation.

Suzuki drz 400E Specifications

General

Displacement	398 cc
Compression Ratio	12.2:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	4-stroke, DOHC
Bore x Stroke	90.0 mm x 62.6 mm
Fuel System	Mikuni BSR36 carburetor
Front Brakes	Disc
Rear Brakes	Disc
Fuel Tank Capacity	10.0 L (2.6 US gallons)
Overall Width	825mm (32.5 inches)
Ground Clearance	315 mm (12.4 in)
Seat Height	935 mm (36.8 in.)
Curb Weight	138 kg (304 lbs)
Dry Weight	119 kg (262 lbs.)
