Suzuki drz 400E Service Manual

ENGINE 3-3
ENGINE REMOVAL AND REMOUNTING
ENGINE REMOVAL
Before taking the engine out of the frame, wash the engine us-
ing a steam cleaner. Engine removal is sequentially explained in
the following steps.
Remove the seat and frame covers. ( 6-2)
Drain the engine oil. ( 2-11)
Drain the engine coolant. ( 2-15)
Remove the carburetor. ( 4-10)
Disconnect the - battery lead wire and engine ground cou-
pler. (DR-Z400E)
Remove the engine side covers.
Remove the engine plate.
Disconnect the generator couplers.
-

Suzuki drz 400E Specifications

General

Displacement	398 cc
Compression Ratio	12.2:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	4-stroke, DOHC
Bore x Stroke	90.0 mm x 62.6 mm
Fuel System	Mikuni BSR36 carburetor
Front Brakes	Disc
Rear Brakes	Disc
Fuel Tank Capacity	10.0 L (2.6 US gallons)
Overall Width	825mm (32.5 inches)
Ground Clearance	315 mm (12.4 in)
Seat Height	935 mm (36.8 in.)
Curb Weight	138 kg (304 lbs)
Dry Weight	119 kg (262 lbs.)
