Suzuki drz 400E Service Manual

SERVICING INFORMATION 8-23
CHASSIS
ITEM N·m kgf-m lb-ft
Handlebar clamp bolt 23 2.3 16.5
Front fork upper clamp bolt 30 3.0 21.5
Front fork lower clamp bolt 32 3.2 23.0
Steering stem head nut 90 9.0 65.0
Front fork cap bolt 23 2.3 16.5
Front fork damper rod bolt 80 8.0 58.0
Front fork inner rod locknut 22 2.2 16.0
Front brake master cylinder mounting bolt 10 1.0 7.0
Rear brake master cylinder mounting bolt 10 1.0 7.0
Brake hose union bolt (front & rear) 23 2.3 16.5
Front brake caliper mounting bolt 26 2.6 19.0
Brake pad mounting pin (front & rear) 18 1.8 13.0
Brake caliper plug (front & rear) 2.5 0.25 1.8
Brake air bleeder valve (front & rear) 7.5 0.75 5.5
Rear brake rod locknut 18 1.8 13.0
Rear brake pedal bolt 29 2.9 21.0
Brake disc mounting bolt (front & rear) 10 1.0 7.0
Front axle nut 42 4.2 30.5
Front axle pinch bolt 18 1.8 13.0
Seat rail mounting nut (upper) 35 3.5 25.5
Seat rail mounting bolt (lower) 35 3.5 25.5
Rear axle nut E-03, 28 100 10.0 72.5
The other countries 110 11.0 79.5
Rear sprocket nut 30 3.0 21.5
Drive chain roller mounting bolt (upper & lower) 40 4.0 29.0
Spoke nipple (front & rear) 3 0.3 2.0
Swingarm pivot nut 77 7.7 55.5
Rear shock absorber compression adjuster assembly 30 3.0 21.5
Rear shock absorber spring adjuster lock ring 90 9.0 65.0
Rear shock absorber mounting nut (upper & lower) 55 5.5 40.0
Cushion lever mounting nut (center) 100 10.0 72.5
Cushion lever mounting nut (front) 100 10.0 72.5
Cushion rod mounting nut 100 10.0 72.5
Side stand bolt 50 5.0 36.0
Side stand nut 55 5.5 40.0

Suzuki drz 400E Specifications

General

Displacement	398 cc
Compression Ratio	12.2:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	4-stroke, DOHC
Bore x Stroke	90.0 mm x 62.6 mm
Fuel System	Mikuni BSR36 carburetor
Front Brakes	Disc
Rear Brakes	Disc
Fuel Tank Capacity	10.0 L (2.6 US gallons)
Overall Width	825mm (32.5 inches)
Ground Clearance	315 mm (12.4 in)
Seat Height	935 mm (36.8 in.)
Curb Weight	138 kg (304 lbs)
Dry Weight	119 kg (262 lbs.)
