10-22 DR-Z400/EK1 (’01-MODEL)
BATTERY (DR-Z400E)
SPECIFICATIONS
Type designation YT7B-BS
Capacity 12V, 21.6 kC (6 Ah)/10HR
INITIAL CHARGING
Filling electrolyte
• Remove the aluminum tape 1 sealing the battery electrolyte
filler holes.
• Remove the caps 2.
NOTE:
* After filling the electrolyte completely, use the removed cap
2
as the sealed caps of battery-filler holes.
* Do not remove or pierce the sealed areas
3 of the electrolyte
container.
• Insert the nozzles of the electrolyte container into the battery’s
electrolyte filler holes, holding the container firmly so that it does
not fall. Take precaution not to allow any of the fluid to spill.
• Make sure air bubbles are coming up each electrolyte container,
and leave in this position for about more than 20 minutes.

Suzuki drz 400E Specifications

General

Displacement	398 cc
Compression Ratio	12.2:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	4-stroke, DOHC
Bore x Stroke	90.0 mm x 62.6 mm
Fuel System	Mikuni BSR36 carburetor
Front Brakes	Disc
Rear Brakes	Disc
Fuel Tank Capacity	10.0 L (2.6 US gallons)
Overall Width	825mm (32.5 inches)
Ground Clearance	315 mm (12.4 in)
Seat Height	935 mm (36.8 in.)
Curb Weight	138 kg (304 lbs)
Dry Weight	119 kg (262 lbs.)
