DR-Z400/EK2 (’02-MODEL) 11-11
SPECIFICATION
ITEM DR-Z400 DR-Z400E
E-01 E-03, 28 E-01 E-03, 28
Main jet (M.J.) #165 #142 #165 #142
Jet needle (J.N.) OBDXP-4th ←←←
Needle jet (N.J.) 2.9 mm
←←←
(0.11 in)
Slow jet (S.J.) #45 ←←←
Slow air jet (S.A.J.) #60 ←←←
Air jet (A.J.) #90 ←←←
Pilot screw (P.S.) 1½ turns back ←←←
Throttle cable play 2 – 4 mm
←←←
(pulling cable) (0.08 – 0.16 in)
RADIATOR + ENGINE COOLANT
ITEM STANDARD/SPECIFICATION NOTE
Radiator cap valve opening 95 – 125 kPa
pressure (0.95 – 1.25 kgf/cm
2
, 13.5 – 17.8 psi)
Engine coolant type
Engine coolant capacity 1 250 ml
(1.3/1.1 US/Imp qt)
BRAKE + WHEEL Unit: mm (in)
ITEM STANDARD/SPECIFICATION LIMIT
Rear brake pedal height 5
(0.2)
———
Brake disc thickness
Front
3.0 ± 0.2 2.5
(0.118 ± 0.008) (0.098)
Rear
4.5 ± 0.2 4.0
(0.177 ± 0.008) (0.16)
Brake disc runout 0.30
———
(0.012)
Master cylinder bore
Front
11.000 – 11.043
(0.4331 – 0.4348)
———
Rear
12.700 – 12.743
(0.5000 – 0.5017)
———
Master cylinder piston diam.
Front
10.957 – 10.984
(0.4314 – 0.4324)
———
Rear
12.657 – 12.684
(0.4983 – 0.4994)
———
Use an anti-freeze/coolant compatible with alumi-
num radiator, mixed with distilled water only, at the
ratio of 50 : 50.
