Suzuki drz 400E Service Manual

11-28 DR-Z400/EK2 (’02-MODEL)
DR-Z400E
THROTTLE POSITION
SENSOR
TAILLIGHT
HEADLIGHT
GENERATOR
IGNITION SWITCH
REGULATOR/RECTIFIER
B
Bl
ON
OFF
ON
OFF
PUSH
RUN
OFF
CLUTCH LEVER
POSITION SWITCH
STATER BUTTON
ENGINE STOP
SWITCH
B/W
B/WB/W
CDI UNIT
IGNITION
COIL
B/Y
Y
Y
Y
Y
Y
Y
Y
W
Bl
G
B
RR
B/W
B/W
Y
Y
+
–
B/W B/W
BATTERY
FUSE BOX
STARTER RELAY
STARTER MOTOR
OO
Y/G B/Y
Y/G
Y/G
Y/G
Y/G
Y/G
B/YB/Y
W
W
W
G
Y
Y Y
B
O
R
R
R
R
Bl
Bl
Bl
B/W
B/W
M
B/WB/W
R/W
R
O
R
O
Gr
B/W
B/W
Gr
O
B/W
O
B/W
W
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
B Bl G Gr O R W Y B/W B/Y Bl/W R/W Y/G
WIRE COLORS
Black Blue Green Gray Orange Red White Yellow Black with White tracer Black with Yellow tracer Blue with White tracer Red with White tracer Yellow with Green tracer

Suzuki drz 400E Specifications

General

Displacement	398 cc
Compression Ratio	12.2:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	4-stroke, DOHC
Bore x Stroke	90.0 mm x 62.6 mm
Fuel System	Mikuni BSR36 carburetor
Front Brakes	Disc
Rear Brakes	Disc
Fuel Tank Capacity	10.0 L (2.6 US gallons)
Overall Width	825mm (32.5 inches)
Ground Clearance	315 mm (12.4 in)
Seat Height	935 mm (36.8 in.)
Curb Weight	138 kg (304 lbs)
Dry Weight	119 kg (262 lbs.)
