General| Displacement | 398 cc |
|---|---|
| Compression Ratio | 12.2:1 |
| Ignition | Electronic ignition (CDI) |
| Transmission | 5-speed constant mesh |
| Rear Suspension | Link type, coil spring, oil damped |
| Front Tire | 80/100-21 |
| Rear Tire | 110/100-18 |
| Engine Type | 4-stroke, DOHC |
| Bore x Stroke | 90.0 mm x 62.6 mm |
| Fuel System | Mikuni BSR36 carburetor |
| Front Brakes | Disc |
| Rear Brakes | Disc |
| Fuel Tank Capacity | 10.0 L (2.6 US gallons) |
| Overall Width | 825mm (32.5 inches) |
| Ground Clearance | 315 mm (12.4 in) |
| Seat Height | 935 mm (36.8 in.) |
| Curb Weight | 138 kg (304 lbs) |
| Dry Weight | 119 kg (262 lbs.) |
