Suzuki drz 400E Service Manual

ENGINE 3-43
DRIVESHAFT BEARINGS
Remove the right and left driveshaft bearings using the spe-
cial tool.
09921-20220: Bearing remover set
Replace the removed bearings with new ones.
Install the right and left driveshaft bearings using the special
tool.
09913-70210: Bearing installer set
CRANKSHAFT BEARINGS
Remove the bearing retainer.
Remove the right and left crankshaft bearings using the spe-
cial tools.
09921-20220: Bearing remover set
Replace the removed bearings with new ones.
Install the right and left crankshaft bearing using the special
tool.
09913-70210: Bearing installer set
RIGHT GEARSHIFT CAM BEARING
Remove the bearing retainer.
Remove the right gearshift cam bearing.
Replace the removed bearing with a new one.
Install the right gearshift cam bearing.

Suzuki drz 400E Specifications

General

Displacement	398 cc
Compression Ratio	12.2:1
Ignition	Electronic ignition (CDI)
Transmission	5-speed constant mesh
Rear Suspension	Link type, coil spring, oil damped
Front Tire	80/100-21
Rear Tire	110/100-18
Engine Type	4-stroke, DOHC
Bore x Stroke	90.0 mm x 62.6 mm
Fuel System	Mikuni BSR36 carburetor
Front Brakes	Disc
Rear Brakes	Disc
Fuel Tank Capacity	10.0 L (2.6 US gallons)
Overall Width	825mm (32.5 inches)
Ground Clearance	315 mm (12.4 in)
Seat Height	935 mm (36.8 in.)
Curb Weight	138 kg (304 lbs)
Dry Weight	119 kg (262 lbs.)
