5-40 CHASSIS
• Tighten the brake hose union bolt 6 to the specified torque.
" Brake hose union bolt: 23 N
.
m (2.3 kgf
.
m, 16.5 lb-ft)
• Tighten the rear torque link nut 7 to the specified torque.
" Rear torque link nut: 35 N
.
m (3.5 kgf
.
m, 25.5 lb-ft)
REAR WHEEL
(! 5-31)
REAR BRAKE
Bleed air from the brake system after remounting the brake
caliper. (! 2-18)
FINAL INSPECTION AND ADJUSTMENT
After installing the rear suspension and rear wheel, adjust the
following before riding.
* Drive chain .............................................. (! 2-14)
* Tire pressure ........................................... (! 2-20)
SUSPENSION SETTING
After installing the rear suspension, adjust the spring pre-load
and damping force as follows.
Spring pre-load adjuster 1
Rebound damping
force adjuster 2
4th 2nd
To Next Page
