CHASSIS 5-57
MASTER CYLINDER REASSEMBLY AND
REMOUNTING
Reassemble and remount the master cylinder in the reverse
order of removal and disassembly. Pay attention to the following
points:
#
* Wash the master cylinder components with new brake
fluid before reassembly.
* Do not wipe the brake fluid off after washing the
components.
* When washing the components, use the specified
brake fluid. Never use different types of fluid or
cleaning solvents such as gasoline, kerosine, etc.
* Apply brake fluid to the master cylinder bore and all of
the master cylinder components before reassembly.
+ Specification and Classification: DOT 4
• Tighten each bolt to the specified torque.
" Master cylinder mounting bolt 1:
23 N
.
m (2.3 kgf
.
m, 16.5 lb-ft)
Master cylinder rod locknut 2:
18 N
.
m (1.8 kgf
.
m, 13.0 lb-ft)
Brake hose union bolt 3: 23 N
.
m (2.3 kgf
.
m, 16.5 lb-ft)
To Next Page
