TB7100 Service Manual Spare Parts 369
© Tait Electronics Limited October 2005
16 Spare Parts
This section lists all serviceable parts (except PCB components).
Table 16.1 Spare parts
Description Qty. IPN Figure
Tray chassis 1 303-11302-xx Figure 7.1
Tray cover 1 303-23169-xx Figure 7.1
Screw M3x6 (cover) 15 345-40460-xx Figure 7.1
Rack mounting bracket 2 302-05279-xx Figure 7.1
Screw M5x8 (rack mounting bracket) 4 346-00005-xx Figure 7.1
Fuse, 20A, 32V, mini-blade 1 265-00011-xx Figure 7.1
Volume control knob 1 311-01054-xx Figure 7.2
UI board (includes fan power board) 1 XBBU100 Figure 7.2
Receiver module (50W/40W version)
Receiver module (25W version)
1 XMAD15-yy03
XMAD13-yy03
Figure 7.3
Transmitter module (50W/40W version)
Transmitter module (25W version)
1 XMAD15-yy02
XMAD13-yy02
Figure 7.4
SI board (includes temperature sensor board) 1 XBBS103 Figure 7.7
Transmitter power cable (4-way to M3.5 spade) (50W/40W version)
Transmitter power cable (4-way to M3.5 spade) (25W version)
1 219-02975-xx
219-02976-xx
Figure 7.9
Receiver power cable (4-way to M3.5 spade) (50W/40W version)
Receiver power cable (4-way to M3.5 spade) (25W version)
1 219-02973-xx
219-02974-xx
Figure 7.9
SI cable (16-way IDC to 15-way D-range) 2 219-02972-xx Figure 7.9
UI cable (18-way IDC to Micro-MaTch) 2 219-02977-xx Figure 7.9
Angled adapter for UI connector 2 240-00021-xx Figure 7.9
Coaxial cable (N-type to BNC) 2 219-02978-xx Figure 7.9
Fan power cable 1 219-02982-xx Figure 7.9
Label for front panel 1 365-01764-xx Figure 3.5
Label Tait TB7100 1 365-01765-xx Figure 3.5
Speaker 1 252-00011-xx Figure 2.1
Screw M3x8 (speaker) 24 345-40470-xx Figure 2.1
Washer M3 (speaker) 2 353-00010-xx Figure 2.1
Fuse 20A, 32V, mini blade 1 265-00011-xx Figure 7.1
Hexagonal screwlock fastener (D-range connectors) 4 354-01043-xx Figure 7.1
Nut M3 Nyloc (N-type connectors) 4 352-00010-xx Figure 7.1
Earthing terminal 1 356-00010-xx Figure 7.1
Heatsink for audio PA 1 303-13152-xx Figure 7.3
