Takeuchi TB295W User Manual

2-17
CONTROLS
MULTI-INFORMATION DISPLAY
WARNING LAMPS
IMPORTANT: If a warning lamp flashes
and an alarm is sounded, immediately
stop all operations and check the
corresponding component.
Refer to “If a warning lamp flashes” on
pages 6-10 and 6-11.
1. ECM error warning lamp
This warning lamp flashes if the Electronic
Control Module (ECM) detects an engine
problem while the starter switch is in the
ON position. The problem detected is
recorded as an ECM error.
Refer to “Engine error code list” on pages
6-14 to 6-17.
1-1. Vehicle and engine emergency lamp
This lamp is displayed enlarged for one
second, and then flashes and an alarm
sounds if there is a problem with the
machine. Go to the (7) Error code
display from the Menu screen, get the
vehicle or engine error code number,
and consult your sales or service dealer
referring to the “Vehicle error code list”
or “Engine error code list” in this manual.
Refer to “Menu screen” on page 2-26.
Refer to “(7) Error code display” on
page 2-29.
Refer to “Vehicle error code list” on
pages 6-12 and 6-13.
Refer to “Engine error code list” on
pages 6-14 to 6-17.
2. Battery charge warning lamp
This lamp flashes and an alarm is sounded
if a problem rises in the charging system
while the engine is running.
3. Engine oil pressure warning lamp
This lamp flashes and an alarm is sounded
if the lubricant oil pressure abnormally low
while the engine is running.
4. Water separator warning lamp
This lamp flashes if the water is detected
within the water separator while the starter
switch is in the ON position.
5. Coolant temperature warning lamp
This lamp flashes and an alarm is sounded
if the engine coolant temperature
becomes abnormally high while the engine
is running.
6. Air cleaner warning lamp
This lamp flashes and an alarm is sounded
if the air cleaner filter is clogged while the
engine is running.
7. Fuel filter warning lamp
This lamp flashes and an alarm is sounded
if the fuel filter is clogged while the engine
is running.
8. Fuel level warning lamp
This lamp flashes when the fuel level is low
while the starter switch is in the ON
position.
9. Third auxiliary hydraulic warning lamp
This lamp starts flashing and an alarm
sounds if the fixed side (left “e”) pressure
of the auxiliary 3rd drops abnormally while
the engine is running, or while the quick-
hitch is being removed or installed.
10. Travel line filter warning lamp
This lamp flashes if the travel line filter is
clogged while the engine is running. This
lamp may flashes directly after the engine
in started in cold weather. This is not a
malfunction. The lamp will turn off as the
engine warms up.
11. Brake oil pressure warning lamp
Wait five seconds after this lamp goes out
before operating the machine.
If this lamp is lit while traveling on a road,
pull off the road as soon as possible.
This lamp lights when the brake oil pressure
becomes abnormally low while the engine is
running.
