Tektronix TDS 220 Service Manual

Replaceable Parts
TDS 200 Series Digital Oscilloscope Service Manual
10–9
Table 10–4 lists the replaceable standard accessories for the oscilloscope and the
instrument options that included them in the original shipment. These accessories
are not shown in Figure 10–1.
Table 10–4: Replaceable standard accessories
Description of accessory Tektronix part number or nomenclature
Passive 1X/10X probes P2100
Replacement user manual
English
French
German
Italian
Spanish
Portuguese
Japanese
Korean
Simplified Chinese
Traditional Chinese
Russian
071-0398-XX
071-0400-XX*
071-0402-XX*
071-0401-XX*
071-0399-XX*
071-0403-XX*
071-0405-XX*
071-0408-XX*
071-0406-XX*
071-0407-XX*
071-0404-XX
Replacement power cords
North American 120 V, 60 Hz
North American 240 V, 60 Hz
Universal European 230 V, 50 Hz
United Kingdom 230 V, 50 Hz
Switzerland 230 V, 50 Hz
Australian 240 V, 50 Hz
China 220 V, 50 Hz
161–0230–01
161–0104–08
161–0104–06
161–0104–07
161–0167–00
161–0104–05
161–0304–00
* These manuals contain a language overlay for the front-panel controls.
Table 10–5: Replaceable optional accessories
Description of accessory Tektronix part number or nomenclature
Soft case AC220
Transit case* HCTDS32
Measurement Extension Module TDS2MM
Communications Extension Module TDS2CM
Rackmount Kit RM200
* Requires the soft case which fits inside.
