Specifications
TDS 200 Series Digital Oscilloscope Service Manual
1–5
Table 1–1: Specifications (cont.)
Trigger
SET LEVEL TO 50%,
typical
Operates with input signals ≥50 Hz
Default Settings, Video
Trigger
Trigger mode is Auto and Coupling is AC
Sensitivity, Video Composite video signal
Trigger Type, typical
Source
Range
Internal Pk-pk amplitude of 2 divisions
TDS 210 and TDS 220
EXT 400 mV
EXT/5 2 V
Signal Formats and Field
Rates, Video Trigger Type
Supports NTSC, PAL, and SECAM broadcast systems for any field or any line
Holdoff Range 500 ns to 10 s
Measurements
Cursors
Voltage difference between cursors (DV)
Time difference between cursors (DT)
Reciprocal of DT in Hertz (1/DT)
Automated Measurements Cycle RMS, Mean, Pk – Pk, Period, Frequency
Table 1–2: General specifications
Display
Display Type 5.9 in (152 mm) diagonal liquid crystal
Display Resolution 320 horizontal by 240 vertical pixels
Display Contrast Adjustable, temperature compensated
Backlight Intensity, typical 60 cd/m
2
Probe compensator output
Output Voltage, typical
5 V into ≥1 MW load
Frequency, typical 1 kHz
Power Source
Source Voltage 100 – 120 VAC
RMS
"10% from 45 Hz through 440 Hz, CAT II
120 – 250 VAC
RMS
"10% from 45 Hz through 66 Hz, CAT II
Power Consumption TDS 210 and TDS 220 TDS 224
Less than 20 W Less than 25 W
Fuse 1 A, T rating, 250 V
