TOHATSU MX 50D2 User Manual

PRE-OPERATING PREPARATIONS 15
4
Consult an authorized dealer for details on
handling of gasoline, if necessary.
Gasoline and its vapors are very flammable
and can be explosive.
When carrying a fuel tank containing gaso-
line:
 Close the air vent screw of fuel tank cap,
or gasoline vapor will be emitted
through the air vent screw, creating a
fire hazard.
 Do not smoke.
When or before refueling :
 Stop the engine, and do not start the
engine during refueling.
 Do not smoke.
 Be careful not to overfill fuel tank. Wipe
up any spilled gasoline immediately.
When or before cleaning the gasoline tank :
 Dismount fuel tank from the boat.
 Place the fuel tank away from every
source of ignition, such as sparks or
open flames.
 Do the work outdoors or in well venti-
lated area.
 Wipe up any spilled gasoline immedi-
ately.
After cleaning gasoline tank :
 Wipe up any spilled gasoline immedi-
ately.
 If the fuel tank is disassembled for
cleaning, reassemble carefully. Imper-
fect assembly may cause a fuel leak,
possibly leading to fire or explosion.
 Dispose of aged or contaminated gaso-
line in accordance with local regulations.
Use of low-quality gasoline results in a
short engine life as well as starting difficul-
ties and other engine problems.
We recommend use for Fuel stabilizer.
Use of unleaded gasoline
Use a major brand of automotive unleaded
gasoline with a minimum posted octane
rating of 91RON. Automotive gasoline that
contain fuel injector cleaner are preferred
for added internal engine cleanliness.
Leaded gasoline is acceptable in areas
where unleaded gasoline is not available.
DANGER
1. Recommended gasoline types
CAUTION
PRE-OPERATING PREPARATIONS
MWX50D2_E.book Page 15 Thursday, August 18, 2011 5:29 PM

TOHATSU MX 50D2 Specifications

General

Engine Type	2-Stroke
Starting	Manual
Gear Ratio	2.08:1
Fuel Type	Gasoline
Oil Type	2-stroke engine oil
Shaft Length	15 inches

Summary

General Safety Information

Safety Warnings and Symbols

Explains DANGER, WARNING, CAUTION, and Note indicators for critical information.

Emergency Stop Switch and Safe Operation

Details the emergency stop switch function and general safe boat operation practices.

Servicing, Maintenance, and Mounting

Outlines recommendations for authorized service, owner maintenance duties, and proper motor mounting.

Specifications

Names of Parts

Installation

Mounting the Outboard Motor on Boat

Instructions for positioning and securing the outboard motor to the boat transom.

Propeller Selection Guide

Guidance on choosing a propeller for optimal engine performance at wide open throttle.

Pre-Operating Preparations

Recommended Gasoline Types

Specifies the type of unleaded gasoline required for optimal engine performance and longevity.

Recommended Engine Oil

Details the type of two-stroke engine oil and fuel-to-oil mixing ratios for operation and break-in.

Break-in Procedure

Outlines the necessary steps for breaking in a new outboard motor for proper component seating and longevity.

Engine Operation

Starting and Warming Up

Procedures for safely starting the engine and warming it up to operating temperature.

Operating Modes and Conditions

Covers forward/reverse engagement, shallow water running, and mooring procedures.

Engine Stopping and Trim Adjustment

Proper engine stopping methods and how to adjust the trim angle for optimal boat handling.

Removing and Carrying the Outboard Motor

Removing the Outboard Motor

Steps required to safely detach the outboard motor from the boat for transport or storage.

Carrying and Storing the Outboard Motor

Guidelines for safely transporting and storing the outboard motor, including preparation steps.

Trailering

Adjustment

Trim Tab Adjustment

How to adjust the trim tab to balance steering loads for straight running.

Steering Load Adjustment

Adjusting the steering resistance for comfortable and safe operation.

Throttle Grip Turning Load Adjustment

Adjusting the friction on the throttle grip for smooth control and preventing accidental movement.

Inspection and Maintenance

Daily Inspection and Checks

Daily checks to perform before and after using the outboard motor for safety and performance.

Basic Maintenance Procedures

Covers washing the motor, and replacing propellers and spark plugs.

Scheduled and Seasonal Maintenance

Outlines periodic servicing, anode inspection, gear oil change, cleaning, storage, and pre-season checks.

Incident Response and Precautions

Procedures for checks after impact, engine submersion, and precautions for cold weather operation.

Troubleshooting

Tool Kit and Spare Parts

Optional Accessories

Propeller Table

Wiring Diagram
