TOHATSU MX 50D2 User Manual

ENGINE OPERATION20
5
In case engine starts in gear, do not start
cruising. Stop engine immediately and con-
sult an authorized dealer.
Note
The engine will not start unless the switch
lock has been properly connected into the
emergency stop switch.
Do not operate the engine with gear case
out of water.
Severe personal injury, or engine damage
will result.
Never fill up portable fuel tanks on board to
avoid fire or explosion resulting from
spilled gasoline. If gasoline is ever spilled
on board, wipe it up thoroughly. Fuel tanks
must always be filled up on land.
Preparations
1 Loosen the air vent screw on the tank
cap.
2 Connect the fuel connector to the
engine.
1. Starting
WARNING
WARNING
CAUTION
ENGINE OPERATION
MWX50D2_E.book Page 20 Thursday, August 18, 2011 5:29 PM

TOHATSU MX 50D2 Specifications

General

Engine Type	2-Stroke
Starting	Manual
Gear Ratio	2.08:1
Fuel Type	Gasoline
Oil Type	2-stroke engine oil
Shaft Length	15 inches
