Toro Workman MDX-D User Manual

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescription
Qty.
Use
Steeringwheel
1
Cover
1
1
Washer(1/2inch)
1
Installthesteeringwheel(Model
07236TConly).
2
Nopartsrequired
–
Connectthebattery(Model07236TC
only).
3
Nopartsrequired
–
Checktheuidlevelsandtireair
pressure.
Operator'sManual
1
Engineowner’smanual1
PartsCatalog
1
Safetytrainingmaterial
1
Registrationcard1
PredeliveryInspectionForm1
CerticateofQuality
1
4
Key2
ReadtheOperator'sManualandview
thetrainingmaterialbeforeoperating
themachine.
5
Nopartsrequired
–
Burnish(break-in)thebrakes.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
InstallingtheSteering
Wheel(Model07236TC
Only)
Partsneededforthisprocedure:
1
Steeringwheel
1
Cover
1
Washer(1/2inch)
Procedure
1.Ifthecoverisinstalled,removeitfromthehub
ofthesteeringwheel(Figure3).
2.Removethelocknut(1/2inch)fromthesteering
shaft(Figure3).
3.Slidethesteeringwheelandwasher(1/2inch)
ontothesteeringshaft(Figure3).
4.Securethesteeringwheeltotheshaftwiththe
locknut(1/2inch)andtightenitto27to34N·m
(20to25ft-lb).
5.Installthecoveronthesteeringwheel(Figure3).
g033840
Figure3
1.Cover4.Steeringwheel
2.Locknut(1/2inch)5.Steeringshaft
3.Washer(1/2inch)
10
