AccessingtheHood
RaisingtheHood
1.Liftupthehandleoftherubberlatchesateach
sideofthehood(Figure25).
g008402
Figure25
2.Raisethehood.
ClosingtheHood
1.Gentlylowerthehoodontothechassis.
2.Securethehoodbyaligningtherubberlatches
ontothelatchanchorsateachsideofthehood
(Figure25).
Lubrication
GreasingtheMachine
ServiceInterval:Every100hours/Yearly(whichever
comesrst)—Greasethebearings
andbushings.Greasethemachine
morefrequentlywhenusingitfor
heavy-dutyoperations.
GreaseType:No.2lithiumgrease
1.Usearagtowipethegreasettingcleansothat
foreignmattercannotbeforcedintothebearing
orbushing.
2.Withagreasegun,apply1or2pumpsofgrease
intothegreasettingsonthemachine.
3.Wipetheexcessgreaseoffthemachine.
Thegreasettingsarelocatedattheinnerendofthe
controlarms(Figure26),thetie-rodballjoint,andthe
outerendofthecontrolarms(Figure27).
g033044
Figure26
LeftSideShown
g033217
Figure27
LeftSideShown
30
