DANGER
Incertainconditionsduringfueling,static
electricitycanbereleasedcausingaspark
whichcanignitethefuelvapors.Areor
explosionfromfuelcanburnyouandothers
andcandamageproperty.
•Alwaysplacefuelcontainersontheground
awayfromyourmachinebeforelling.
•Donotllfuelcontainersinsideamachine
oronatruckortrailerbedbecauseinterior
carpetsorplastictruckbedlinersmay
insulatethecontainerandslowthelossof
anystaticcharge.
•Whenpractical,removefuel-powered
equipmentfromthetruckortrailerand
refueltheequipmentwithitswheelsonthe
ground.
•Ifthisisnotpossible,thenrefuelsuch
equipmentonatruckortrailerfroma
portablecontainer,ratherthanfroma
fuel-dispensernozzle.
•Ifayoumustuseafuel-dispensernozzle,
keepthenozzleincontactwiththerimof
thefueltankorcontaineropeningatall
timesuntilfuelingiscomplete.
FillingtheFuelTank
Thefueltankcapacityisapproximately26.5L(7US
gallons).
1.Shutofftheengineandengagetheparking
brake.
2.Cleantheareaaroundthefuel-tankcap(Figure
20).
g008398
Figure20
1.Empty4.Fuelgauge
2.Full5.Fuel-tankcap
3.Needle
3.Removethefuel-tankcap.
4.Fillthetanktoabout25mm(1inch)belowthe
topoftank,(bottomofthellerneck).
Note:Thisspaceinthetankallowsfuelto
expand.Donotoverllthefueltank..
5.Installthefueltankcapsecurely.
6.Wipeupanyfuelthatmayhavespilled.
StartingtheEngine
Important:Donotattempttopushortowthe
machinetogetitstarted.
1.Sitintheoperator'sseat,insertthekeyintothe
keyswitch,pressdownonthebrake,androtate
thekeyclockwisetotheONposition.
Note:Ifthebackupalarmisinstalledandthe
gear-shiftselectorisintheREVERSEposition,
thebuzzersoundstowarntheoperator.
2.Whentheglow-plug-indicatorlightturnsoff,
rotatethekeyclockwisetotheSTARTposition.
3.Whentheenginestarts,turnthekey
counterclockwisetotheRUNposition.
4.Disengagetheparkingbrake.
23
