TP-Link TL-WR841HP User Manual

-106-
TL-WR841HP
300Mbps High Power Wireless N Router
4.3.3 Wireless
There are six submenus under the Wireless menu: Wireless Settings, Wireless Security,
Wireless Mac Filtering, Wireless Advanced, Wireless Statistics and Throughput Monitor.
Click any of them, and you will be able to configure the corresponding function. The detailed
explanations for each submenu are provided below.
4.3.3.1. Wireless Settings
Go to “Setting→Wireless→Wireless Settings”, and then you can configure the basic settings
of wireless network.
 Wireless Name of Root AP - The SSID of the AP your device is going to connect to as a
client. You can also click the Survey button to search the AP to join, and then this field will
be filled automatically.
 MAC Address of Root AP - The MAC address of the AP your device is going to connect to
as a client. You can also click the Survey button to search the AP to join, and then this field
will be filled automatically.
 Mode -This field determines the wireless mode which the AP works on.

TP-Link TL-WR841HP Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Number of guest networks (2.4 GHz)	1
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
USB port	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	Dynamic IP, Static IP, PPPoE, PPTP, L2TP
NAT functionality	Virtual Server Port Forwarding Port Triggering DMZ UPnP
Security algorithms	WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Transmit power	30 dBmW
Antennas quantity	2
Antenna connector type	-
Antenna gain level (max)	9 dBi
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Product type	Tabletop router
Product color	Black
Cables included	LAN (RJ-45)
WAN connection type	RJ-45
Output current	1 A
Output voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	190 mm
Width	227.5 mm
Height	48.3 mm
