1. Click the Add New... button.
2. Enter the MAC Address and IP Address.
3. Select the Bind checkbox.
4. Click the Save button to save it.
To modify or delete an existing entry, follow the steps below.
1. Find the desired entry in the table.
2. Click Modify or Delete as desired on the Modify column.
To find an existing entry, follow the steps below.
1. Click the Find button on Binding Settings page.
2. Enter the MAC Address or IP Address.
3. Click the Find button.
Click the Enable All button to make all entries enabled.
Click the Delete All button to delete all entries.
3.4.14 ARP List
Go to “Advanced→Bandwidth Control→ARP List”, you can see the ARP List, showing all the
existing IP & MAC Binding entries as shown below. To manage the computer, you could
observe the computers in the LAN by checking the relationship of MAC address and IP address
on the ARP list, and you could also configure the items on the ARP list.
1. MAC Address - The MAC address of the controlled computer in the LAN.
2. IP Address - The assigned IP address of the controlled computer in the LAN.
3. Status - Indicates whether or not the MAC and IP addresses are bound.
4. Configure - Load or delete an item.
Load - Load the item to the IP & MAC Binding list.
