TP-Link TL-WR841HP User Manual

-74-
TL-WR841HP
300Mbps High Power Wireless N Router
 Subnet Mask - The Subnet Mask determines which portion of an IP address is the network
portion, and which portion is the host portion.
 Gateway - This is the IP address of the gateway device that allows for contact between the
router and the network or host.
 Interface - This interface tells you either the Destination IP Address is on the LAN &
WLAN (internal wired and wireless networks), or on the WAN (Internet).
3.4.12 Bandwidth Control
There are two submenus under the Bandwidth Control menu: Control Settings and Rules List.
Click any of them, and you will be able to configure the corresponding function. The detailed
explanations for each submenu are provided below.
3.4.12.1. Control Settings
Go to “Advanced→Bandwidth Control→Control Settings”, and then you can configure the
Egress Bandwidth and Ingress Bandwidth in the next screen. For optimal control of the
bandwidth, please select the right Line Type and ask your ISP for the total bandwidth of the
egress and ingress.
 Enable Bandwidth Control - Select this checkbox so that the Bandwidth Control settings
can take effect.
 Line Type - Select the right type for you network connection. If you don’t know how to
choose, please ask your ISP for the information.
 Egress Bandwidth - The upload speed through the Internet port.
 Ingress Bandwidth - The download speed through the Internet port.

TP-Link TL-WR841HP Specifications

General

Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1x
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Number of guest networks (2.4 GHz)	1
Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
USB port	No
Ethernet LAN (RJ-45) ports	4
Supported network protocols	Dynamic IP, Static IP, PPPoE, PPTP, L2TP
NAT functionality	Virtual Server Port Forwarding Port Triggering DMZ UPnP
Security algorithms	WEP, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise
Transmit power	30 dBmW
Antennas quantity	2
Antenna connector type	-
Antenna gain level (max)	9 dBi
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Product type	Tabletop router
Product color	Black
Cables included	LAN (RJ-45)
WAN connection type	RJ-45
Output current	1 A
Output voltage	12 V
Power source type	DC

Weight and Dimensions

Depth	190 mm
Width	227.5 mm
Height	48.3 mm
